Industrial Auto-Tilting Cooking Mixer: Large Capacity Planetary Stirring Jacketed Kettle
Tindo's Auto-Tilting Cooking Mixer is a high-performance industrial solution for precision food processing. Featuring a hydraulic tilting system and planetary stirring mechanism, this machine ensures effortless discharge and uniform mixing for viscous products. Ideal for industrial kitchens, sauce production, and ready-meal facilities, it supports multiple heating options, including Steam, Gas, Electric, and Induction.
Feature-Benefit of Auto-Tilting Cooking Mixer:
Planetary Stirring (360° Coverage): The scraping bottom and sides ensure no scorched spots, making it perfect for thick pastes and delicate sauces.
Automated Hydraulic Tilting: Precise 90-degree tilting allows for rapid, safe discharge of high-volume batches (up to 1000L).
Advanced Temperature Control: Real-time monitoring with PT100 sensors ensures consistent quality for heat-sensitive ingredients like caramel or chocolate.
Food-Grade Durability: Fully constructed from AISI 304/316 stainless steel, meeting global hygiene standards (CE/ISO).
Safety Interlocks: Equipped with emergency stops and heat-insulated jackets to protect operators in high-speed production environments.
Intelligent Cooking Automation
✓ One-Touch Hydraulic Tilting: Safely discharge 200L-2000L batches in <30 seconds
✓ Dual Heat & Mix Control: Steam/Electric/Thermal Oil heating with ±0.5°C accuracy
✓ Programmable Recipes: Save 50+ cooking profiles (time/temp/rpm)
✓ Zero-Residue Design: Self-cleaning spray ball + CIP compatibility
Industry Applications
Sauces & Condiments: Tomato paste, BBQ sauce, hot pot base (50-5000kg/day)
Meal Prep: Curry, chili, sous-vide protein blends
Dairy Alternatives: Vegan cheese, plant-based cream
Retort Foods: Sterilized meals for military/airline supply
Suggestions for the different industries and capacities:
| Industry Category | Typical Applications | Batch Output | Recommended Capacity |
| Sauces/Condiments | Curry Paste, Ketchup, Concentrated Soup Base | 100–300 kg/batch | 300 L – 600 L |
| Confectionery/Baking | Caramel, Lotus Seed Paste, Chocolate Melting | 50–200 kg/batch | 100 L – 400 L |
| Meat Products | Braised Meats, Meat Sauces, Pet Food Processing | 300–500 kg/batch | 600 L – 1000 L |
Operational Cost Savings
Labor Reduction: 1 operator manages 3x batch volume
Energy Efficiency: 30% lower steam consumption vs. fixed kettles
Waste Minimization: <1% product residue after discharge
FAQ
Q: What heating sources are available?
A: Gas, Steam, Electric, and Induction.
Q: Is the stirring speed adjustable?
A: Yes, it features VFD speed regulation from 0 to 30 RPM.
Q: What is the materials of the bowl of this cooking mixer?
A: It is made from SUS304 materials, also cutomized SUS316L according to your requirments.
